SABAR H1 Dual Remote Bypass Oil Filter System – 6.5L Turbo Diesel
Cleaner oil, more of it, and two filters you can reach. Built for the 6.5 Turbo.
The 6.5L Turbo Diesel is hard on oil. Soot loading, heat, and long idle time break it down, and a single factory filter only catches the bigger particles. The SABAR H1 Dual Remote Bypass Oil Filter System replaces the stock filter with a frame-mounted head carrying two filters: a high-quality full-flow filter that protects...
Cleaner oil, more of it, and two filters you can reach. Built for the 6.5 Turbo.
The 6.5L Turbo Diesel is hard on oil. Soot loading, heat, and long idle time break it down, and a single factory filter only catches the bigger particles. The SABAR H1 Dual Remote Bypass Oil Filter System replaces the stock filter with a frame-mounted head carrying two filters: a high-quality full-flow filter that protects the engine on every pass, and a large bypass filter that pulls out the fine soot and wear particles a standard filter lets through.
Running a non-turbo 6.2 or 6.5? This kit isn't for your engine. Contact us and we'll point you to the right setup.
Two filters, two jobs
| Full-flow filter | Bypass filter | |
|---|---|---|
| What it does | Replaces the stock filter and protects the engine on every pass | Catches the fine soot and wear particles full-flow filters can't |
| Oil flow | All of it | About 10%, continuously |
| Particle size | Standard full-flow filtration | Down to about 2 microns |
| How often the oil is cleaned | Every pass | The whole oil supply, several times an hour |
What you get
- Cleaner oil, all the time. The bypass filter removes the fine soot a diesel produces, so bearings, cam, and turbo see cleaner oil.
- More oil in the system. Two filters and the lines add capacity, which helps with oil cooling.
- Easier service. Both filters hang from one remote head instead of the factory location on the block.
- Longer drain intervals, done right. Pair the kit with oil analysis to stretch your intervals safely.
Built for the H1, not adapted to it
- Remote dual filter head on a stainless frame-mount bracket with backing plates, so it bolts to the frame rail without drilling the engine.
- Pre-made braided oil lines. The fittings are already installed, with nothing to cut or crimp.
- Engine block adapter replaces the stock filter mount, with 90° adapters to route the lines cleanly.
- Two premium synthetic-media filters included. A full-flow filter and a large bypass filter come in the box, ready to spin on.
Fitment
- Every Hummer H1 with the 6.5L Turbo Diesel.
- HMMWV M11xx-series trucks with the 6.5L Turbo Diesel, including the M1113, M1114, M1116, M1151, M1152, M1165, and M1167.
- Turbo only. Does not fit naturally aspirated (non-turbo) 6.2 or 6.5 engines, or gas engines. Some 11xx trucks, like the M1123, came with the non-turbo 6.5 and aren't covered.
Not sure? Contact us with your year and engine before you order and we'll confirm the fit.
In the box
- SABAR H1 dual remote filter head
- Large bypass oil filter
- Full-flow oil filter
- Engine block adapter that replaces the stock filter mount
- Stainless frame-mount bracket
- (2) Backing plates with bolts and nuts
- Pre-made braided oil lines with fittings installed
- 90° adapters for the block connection
- Installation instructions
Specifications
| Fits | 6.5L Turbo Diesel: all H1, HMMWV M11xx series |
| Filters | 2: (1) full-flow, (1) bypass |
| Filter media | Synthetic |
| Bypass filtration | Down to about 2 microns, about 10% of oil flow |
| Mounting | Remote, frame rail |
| Oil lines | Pre-made braided, fittings installed |
| Install time | About 2 hours |
| Warranty | 1 year |
| Made in | USA |
Installation
Bolt-on install with basic hand tools, about 2 hours. No permanent modifications. The block adapter replaces the stock filter mount, the filter head bolts to the frame rail on the supplied bracket, and the pre-made lines connect the two. Installation instructions are included.
Buy with confidence
- 1-year warranty
- Ships from Thousand Oaks, CA within 2–3 business days; 3–7 business days transit in the USA
- 30-day returns on unused items in original packaging (20% restocking fee)
- Made in USA. Designed and built for the H1 and HMMWV by SABAR H1.
FAQ
Does this replace my stock oil filter?
Yes. The block adapter takes the place of the factory filter mount, and the full-flow filter in the kit does the stock filter's job from the remote head.
Will it fit my non-turbo 6.5 or 6.2?
No. This kit is for the 6.5L Turbo Diesel only. Contact us about NA engines.
Do I have to cut or build any hoses?
No. The braided oil lines come pre-made with the fittings installed.
How long does it take to install?
About 2 hours with basic hand tools, and nothing on the truck is permanently modified.
How often do I change the bypass filter?
Follow the service interval printed on the bypass filter, and change the full-flow filter with your oil. Oil analysis is the best way to set your own intervals.
Does it add oil capacity?
Yes. The second filter and the lines hold extra oil, so check the dipstick after the first fill and top up.
